All about SYM T2 250i

1. T2 size and weight[u/]

Car length Overall Length: 2005 mm
CHE wide Overall Width: 790 mm
Ride Height Overall the Height: 1050 mm
Handle width / height of the Handle Grip the Width / Height: 755 mm　/ 1000 mm
Wheelbase Wheel Base: 1320 mm
Seat height Seatl Height: 790 mm
Ground Clearance Ground, Primal Pictures Clearance: 150 mm
Body weight Curb Weight: 173 kg
Fuel tank capacity of the Fuel the Capacity: 14.0 liter

2. T2 performance

The highest rate Maximun Speed: 140 km / h or more
The fuel consumption of the Fuel Consumption (at 40 km / h): > 41 km / l
Climbing ability Climbing Ability: > 28 deg
Radius of gyration Turning Circle (Radius): 2.6 m,
Braking distance Stopping Distance (at 50 km / h): < 14 m

The data included in this table are the original laboratory test proceeds, may be due to the external environment, riding habits vary with the actual situation.

3. T2 engine and transmission


Engine in the form Type: Four-stroke single-cylinder water-cooled
Number of cylinders Cylinder Arrangement Pre - Order: Single-cylinder
Cylinder bore / stroke for Cylinder Bore / the Stroke: φ71 ? 63 mm
Compression Ratio Compression Ratio: 10.5: 1
Total displacement Displacement: 249.4 cm
Tensioner Tensioner: auto
Maximum horsepower the Maximum Horsepower: 25 ps / 7500 rpm
Maximum torque the Maximum the Torque: 2.35 kg-m 　/ 6000 rpm
Lubrication way Lubrication the System: forced and wet sump
Use the fuel the Fuel the Required: Unleaded gasoline
Air Filter Air Filtration: paper the filter
Noise Emission of noise figure: < 77 dB,
Engine weight (NW) Engine Weight (dry weight): 37 kg
Clutch Clutch: wet mutiplate
Transmission: International six-speed

4. T2 frame with wheels

Frame Type Frame Type: Diamond frame
Frame material the Frame Material: steel
Suspension Type (front / rear) Suspension Type (front / rear): telescopic the fork / unit swing
Suspension travel (front / rear) Suspension Travel: 20 mm　/ 125 mm
Wheel size (front / rear) Rim, Size: The MT 3.00 ? 17 / MT 3.50 ? 17
Tire form of Tire's the Type: tubeless
Tire Size Tire Size : Front 110 / 70-17 　Rear / 140 / 70-17
Brake type (front / rear) Brake Type: Front disc / after dish
Brake disc diameter Brake the Disk the Diameter: φ288 mm　/ φ222 mm

5. T2 power installed components

Ignition device Ignition, the System: Full transistor ignition
Startup mode Starting the System: Electric
Generator Alternator: 114 the W / 5000 rpm
Battery Specifications Battery the Capacity: The 12 V 10Ah
Speedometer Speedometer Scale: 0 to 199 km / h
Speaker volume Horn, the Volume: 80 to 112 dB
The spark plug the Spark Plug: NGK CR8E
Headlights (much / beam) Headlight (deep / main beam): 12 V 60 W / 55 W
Taillights, brake lights Taillight / Stoplight: The 12 V LED
The front position lamp (left / right) Front the Position Lamp: 12 V 5 W ? 2
Direction of light (front / rear) Turn the Signal Light: 12 V 10 W ? 2/12 V 10 W ? 2
Reflective piece Reflex Reflector: A
